- Dimensions: 358 x 207 x 451mm (DWH)
- Form Factor: Mid Tower
- Materials: Steel+Plastic
- Mainboard Support: ATX, Micro-ATX, ITX
- Front Access & Controls: Power,Reset, 2 x USB 2.0, 1 XUSB 3.0, MIC / HD-AUDIO
- Side Panel: Tempered glass
Drive Bays
-
Expansion Slots 7 3.5″ /2.5″ 2 / 1 2.5″ 2
Fan Support
-
Front 3 x 120mm / 2 x 140mm Top 2 x 120mm Power supply 2 x 120mm Rear 1 x 120mm Included Fan(s) 3 x 120 RGB fixed model fans in front (AX20)
3 x 120 RGB fixed mode fans in front + 1 x 120 RGB fixed mode fan in rear (AX20 Elite)
Radiator Support
| Front | 120 / 140 / 240 / 280mm |
Clearance
| Max GPU Length | ≤ 270mm |
| Max CPU Cooler Height | ≤ 155mm |
| Max PSU Length | ≤ 170mm(with HDD) ≤ 295mm(without HDD) |
Miscellaneous
| Dust Filter | Front |
| Net Weight | 4 Kg (AX20) / 4.12 Kg (AX20 Elite) |
| Gross Weight | 4.71 Kg (AX20) / 4.83 Kg (AX20 Elite) |
| Warranty | 1 year |
| UPC# | 0-761345-10060-1 (AX20) 0-761345-10066-3 (AX20 Elite) |
