Product Specifications
• Dimensions: 178mm × 70mm × 217.2mm
• Color: Dark Grey
Hardware Specifications
• Antenna: 4 high-performance internal antennas
• NFC: Supported
• Bluetooth Mesh Gateway: Supported
• Network Ports: 1 × 2.5Gbps + 3 × 1Gbps (WAN/LAN auto-sensing)
• Indicator: x1
• Mesh/Reset Button: x1
• Power Port: x1
• Protocol Standard: IEEE 802.11a/b/g/n/ac/ax/be, IEEE 802.3/3u/3ab
Wireless Specifications
• Bands: 2.4GHz, 5GHz
• 2.4GHz Wi-Fi: 688Mbps (802.11be)
• 5GHz Wi-Fi: 2882Mbps (802.11be)
Software Specifications
• Operating System: MiWiFi ROM
• Wi-Fi Encryption: WPA-PSK, WPA2-PSK, WPA3-SAE
• Management Applications: Web, Xiaomi Home App (Android, iOS)
Working Environment
• Operating Temperature: 0–40°C
• Operating Humidity: 10%–90% RH (non-condensing)
• Storage Temperature: -40–70°C
• Storage Humidity: 5%–90% RH (non-condensing)
